Agco-Allis/Allis-Chalmers/Deutz-Allis
5 INCH - HAND CLUTCH/FINAL DRIVE
Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: CA, ED 40


Agco-Allis/Allis-Chalmers/Deutz-Allis
6-1/2 INCH - SINGLE STAGE
Clutch Kit
Part #:351760N AC-KIT
 Includes: 351760, D800662, N1054


Pressure Plate
Part #:351760
Reference #: 1500362M92
Reference #: CA5256
Reference #: D800023
 Type - Lever
 Casting O.D. - 6-1/2"
 Levers - 3
 Springs - 6
 Stage -Single

 Models: G

Disc
Part #:351773
Reference #: 1500374M92
 Type - Rigid Woven
 Disc O.D - 6-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: G

Release Bearing
Part #:N1054
 OD - 2.7344

 Models: G

Pilot Bearing
Part #:251266
 I.D - 0.627"
 O.D - 0.815"
 Thickness - 1.060"

 Models: G

Alignment Tool
Part #:AT 5336
 Large Spline - 15/16" x 10
 Small Spline - N/A
 Pilot Diameter - .625

 Models: G


Agco-Allis/Allis-Chalmers/Deutz-Allis
7-1/4 INCH - SINGLE STAGE
Clutch Kit
Part #:1273243N KIT-ALLIS
 Includes: 1273242, 1273243, 6002-2RS, N3804

 Models: 5015

Clutch Kit
Part #:1273243N KIT-ALLIS-2
 Includes: 1273242, 1273243

 Models: 5015

Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 5015

Disc
Part #:1273242
 Type - Spring Organic
 Disc O.D - 7-1/4"
 Disc Hub Size - 3/4"
 Disc Spline - 10

 Models: 5015

Release Bearing
Part #:N3804
Reference #: 834081
Reference #: N4081
 ID - 1.574"
 OD - 2.500"
 Thickness - .610"

 Models: 5015

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 5015

Clutch Kit
Part #:1273243N KIT-ALLIS
 Includes: 1273242, 1273243, 6002-2RS, N3804

 Models: 5215

Clutch Kit
Part #:1273243N KIT-ALLIS-2
 Includes: 1273242, 1273243

 Models: 5215

Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 5215

Disc
Part #:1273242
 Type - Spring Organic
 Disc O.D - 7-1/4"
 Disc Hub Size - 3/4"
 Disc Spline - 10

 Models: 5215

Release Bearing
Part #:N3804
Reference #: 834081
Reference #: N4081
 ID - 1.574"
 OD - 2.500"
 Thickness - .610"

 Models: 5215

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 5215


Agco-Allis/Allis-Chalmers/Deutz-Allis
8 INCH - SINGLE STAGE
Clutch Kit
Part #:1273254NKIT-YANMAR-2
 Includes: 1273254, M3281107

 Models: 5220

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 5220

Disc
Part #:M3281107
 Type - Spring Organic
 Disc O.D - 8"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5220

Disc
Part #:M3281106
 Type - Rigid Organic
 Disc O.D - 8"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5220

Release Bearing
Part #:N3804
Reference #: 834081
Reference #: N4081
 ID - 1.574"
 OD - 2.500"
 Thickness - .610"

 Models: 5220

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 5220


Agco-Allis/Allis-Chalmers/Deutz-Allis
8-1/2 INCH - SINGLE STAGE
Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: B

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: C, CA

Clutch Kit
Part #:D2098568N KIT-2
 Includes: D2098568, K32420

 Models: 5020

Pressure Plate
Part #:D2098568
 Casting O.D. - 8-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 5020

Disc
Part #:K32420
Reference #: R18375
 Type - Spring Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5020

Disc
Part #:K32420-R
Reference #: CD2425
Reference #: R18374
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5020

Disc
Part #:K32420 HD4
Reference #: CD2425 HD4
Reference #: R18374 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5020

Disc
Part #:K32420-HD-6
Reference #: K32420-1440-CB
Reference #: R18375 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5020

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 5020

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 5020

Clutch Kit
Part #:D2098568N KIT-2
 Includes: D2098568, K32420

 Models: 5030

Pressure Plate
Part #:D2098568
 Casting O.D. - 8-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 5030

Disc
Part #:K32420
Reference #: R18375
 Type - Spring Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5030

Disc
Part #:K32420-R
Reference #: CD2425
Reference #: R18374
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5030

Disc
Part #:K32420 HD4
Reference #: CD2425 HD4
Reference #: R18374 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5030

Disc
Part #:K32420-HD-6
Reference #: K32420-1440-CB
Reference #: R18375 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: 5030

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 5030

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 5030


Agco-Allis/Allis-Chalmers/Deutz-Allis
8-1/2 INCH - DUAL STAGE
Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST28A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST28A

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST30X

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST30X

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST33A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST33A

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 5220

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 5220

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 5230

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 5230


Agco-Allis/Allis-Chalmers/Deutz-Allis
9 INCH - 10 SPLINE
Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D10

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D10

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D10

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D10

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D12

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D12

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D12

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D12

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D14

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D14

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D14

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D14

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D15

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D15

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: D15

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D15

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I40

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I40

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I40

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I40

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I60

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I60

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I60

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I60

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I600

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I600

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: I600

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I600

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: 615 Backhoe

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 615 Backhoe

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 615 Backhoe

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 615 Backhoe


Agco-Allis/Allis-Chalmers/Deutz-Allis
9 INCH - 24 SPLINE
Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D10

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D10

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: D12

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D12

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I40

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I40

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I60

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I60

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: I600

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: I600


Agco-Allis/Allis-Chalmers/Deutz-Allis
9 INCH - SINGLE STAGE #1
Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: HD3

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: HD3

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: HD3

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: HD3

Pressure Plate
Part #:M185923
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 Models: HD4

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: HD4

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: HD4

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: HD4

Pressure Plate
Part #:Y194335
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: ST30

Disc
Part #:M3703735
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30

Disc
Part #:M3703735 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30

Disc
Part #:M3703735 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30

Disc
Part #:M3703736
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: ST30

Pressure Plate
Part #:Y194335
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: ST30X

Disc
Part #:M3703735
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30X

Disc
Part #:M3703735 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30X

Disc
Part #:M3703735 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30X

Disc
Part #:M3703736
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST30X

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: ST30X

Disc
Part #:M3703735
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Disc
Part #:M3703735 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Disc
Part #:M3703735 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Disc
Part #:M3703736
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST35

Pilot Bearing
Part #:6202-2RS
 I.D - 0.590"
 O.D - 1.375"
 Thickness - .430"

 Models: ST35

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: ST35


Agco-Allis/Allis-Chalmers/Deutz-Allis
9 INCH - SINGLE STAGE #2
Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: B

Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: B, RC


Agco-Allis/Allis-Chalmers/Deutz-Allis
9-1/2 INCH - SINGLE STAGE
Disc
Part #:M3756828
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Disc
Part #:FD320150
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST35

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST35

Disc
Part #:M3756828
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35X

Disc
Part #:FD320150
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST35X

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST35X

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST35X

Disc
Part #:M3756828
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST40

Disc
Part #:FD320150
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST40

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST40

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST40

Disc
Part #:M3756828
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST40X

Disc
Part #:FD320150
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST40X

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST40X

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST40X


Agco-Allis/Allis-Chalmers/Deutz-Allis
9-1/2" SINGLE STAGE - SYNCHRO AND POWER SHUTTLE
Clutch Kit
Part #:K20206N KIT
 Includes: 6002-2RS, AG 55, FD320160, K20206, RCT55B

 Models: ST34A

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: ST34A

Disc
Part #:FD320160
Reference #: F400441
Reference #: R127829
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19"

 Models: ST34A

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: ST34A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST34A

Alignment Tool
Part #:AG 55
 Large Spline - 1-3/8" - 19
 Pilot Diameter - .590

 Models: ST34A

Clutch Kit
Part #:K20206N KIT
 Includes: 6002-2RS, AG 55, FD320160, K20206, RCT55B

 Models: ST41A

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: ST41A

Disc
Part #:FD320160
Reference #: F400441
Reference #: R127829
 Type - Rigid Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19"

 Models: ST41A

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: ST41A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST41A

Alignment Tool
Part #:AG 55
 Large Spline - 1-3/8" - 19
 Pilot Diameter - .590

 Models: ST41A


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH - SINGLE STAGE
Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: WC

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: WC

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: WC

Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: WD

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: WD

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: WD

Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: WD45

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: WD45

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: WD45

Release Bearing
Part #:N1167
Reference #: 832063
Reference #: RCB6136C
 ID - 2.062"
 OD - 3.328"
 Thickness - 0.750"

 Models: WF

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: WF

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: WF


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH STEERING CLUTCH - SINGLE STAGE
Pressure Plate
Part #:676827
 Type - Lever
 Casting O.D. - 10"
 Levers - 3
 Springs - 9
 Stage -Single

 Models: HD3

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: HD3

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: HD3

Pressure Plate
Part #:676827
 Type - Lever
 Casting O.D. - 10"
 Levers - 3
 Springs - 9
 Stage -Single

 Models: HD4

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: HD4

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: HD4

Pressure Plate
Part #:676827
 Type - Lever
 Casting O.D. - 10"
 Levers - 3
 Springs - 9
 Stage -Single

 Models: 653

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 653

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 653

Pressure Plate
Part #:676827
 Type - Lever
 Casting O.D. - 10"
 Levers - 3
 Springs - 9
 Stage -Single

 Models: 655

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 655

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 655


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH - DUAL STAGE 1
Disc
Part #:D2092068
 Type - Rigid Woven
 Disc O.D - 10"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: 5040

Disc
Part #:D2089813
Reference #: D2089813
 Type - Rigid Woven
 Disc O.D - 10"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 5040

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 5040

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 5040

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 5040


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH - DUAL STAGE #2
Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 160

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 160

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 6040

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 6040


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH - DUAL STAGE #3
Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: 4650

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 4650


Agco-Allis/Allis-Chalmers/Deutz-Allis
10 INCH - DUAL STAGE #4
Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 5650

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 5650

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 5650

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 5650


Agco-Allis/Allis-Chalmers/Deutz-Allis
10-3/8 INCH - SINGLE STAGE
Disc
Part #:M3705750
 Type - Rigid Organic
 Disc O.D - 10-3/8"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST45

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST45

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: ST45

Disc
Part #:M3705750
 Type - Rigid Organic
 Disc O.D - 10-3/8"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST45H

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST45H

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: ST45H


Agco-Allis/Allis-Chalmers/Deutz-Allis
11 INCH - SINGLE STAGE
Pressure Plate
Part #:K32530
Reference #: 3A481-25110
Reference #: SC32232
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single
 12-5/8" Hole Center To Center

 Models: ST47A

Disc
Part #:M01250067
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: ST47A

Disc
Part #:M01250067 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: ST47A

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: ST47A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST47A

Pressure Plate
Part #:K32530
Reference #: 3A481-25110
Reference #: SC32232
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single
 12-5/8" Hole Center To Center

 Models: ST52A

Disc
Part #:M01250067
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: ST52A

Disc
Part #:M01250067 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: ST52A

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: ST52A

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: ST52A


Agco-Allis/Allis-Chalmers/Deutz-Allis
11 INCH - SINGLE STAGE #2
Pressure Plate
Part #:52840

 Models: D17

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 SERIAL #74999 AND BELOW

 Models: D17

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 SERIAL #75000 AND ABOVE

 Models: D17

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: D17

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: D17

Pressure Plate
Part #:52840

 Models: HD4

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: HD4

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: HD4

Pressure Plate
Part #:52840

 Models: M65

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: M65

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: M65

Disc
Part #:M3707177
 Type - Rigid Organic
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST55

Disc
Part #:M3707177 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: ST55

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: ST55

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: ST55

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 170

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 170

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 170

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 175

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 175

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 175


Agco-Allis/Allis-Chalmers/Deutz-Allis
11 INCH - SINGLE STAGE 4
Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: D19

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: D19

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: D19


Agco-Allis/Allis-Chalmers/Deutz-Allis
11 INCH - DUAL STAGE
Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 4650

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 4650

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 Models: 5040

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: 5040

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5040

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5040

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 5040

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 5040

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 5040

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 5040

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 5040

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 5040

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 Models: 5045

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: 5045

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5045

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5045

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 5045

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 5045

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 5045

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 5045

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 5045

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 5045

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 Models: 5050

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: 5050

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5050

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 5050

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 5050

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 5050

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 5050

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 5050

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 5050

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 5050

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 Models: 6060

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: 6060

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 6060

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 6060

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 6060

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 6060

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 6060

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 6060

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 6060

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 6060

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 Models: 6070

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: 6070

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 6070

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 Models: 6070

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 Models: 6070

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 6070

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 6070

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 6070

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 6070

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: 6070


Agco-Allis/Allis-Chalmers/Deutz-Allis
11 INCH - DUAL STAGE #2
Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: 6140

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 6140


Agco-Allis/Allis-Chalmers/Deutz-Allis
12 INCH - CLUTCH TORQUE LIMITER - POWER DIRECTOR
Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 4W220

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 4W220

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7010

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7010

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7020

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7020

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7030

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7030

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7040

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7040

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7045

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7045

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7050

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7050

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7060

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7060

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7080

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7080

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7580

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 7580

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8010

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8010

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8030

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8030

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8050

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8050

Disc
Part #:D269728
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8070

Disc
Part #:D269728-UL
 Type - Spring Unlined
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 23

 Models: 8070


Agco-Allis/Allis-Chalmers/Deutz-Allis
12 INCH - SINGLE STAGE #1
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 7000

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 7000


Agco-Allis/Allis-Chalmers/Deutz-Allis
12 INCH - SINGLE STAGE #2
Pressure Plate
Part #:D255689
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Flywheel Step - 1.437"
 Stage -Single

 7" CAST ID
 CAN USE IN PLACE OF 6" CAST ID

 Models: 180

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 180

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 180

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 180

Pressure Plate
Part #:D255689
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Flywheel Step - 1.437"
 Stage -Single

 7" CAST ID
 CAN USE IN PLACE OF 6" CAST ID

 Models: 185

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 185

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 185

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 185

Pressure Plate
Part #:D255689
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Flywheel Step - 1.437"
 Stage -Single

 7" CAST ID
 CAN USE IN PLACE OF 6" CAST ID

 Models: 190

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 190

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 190

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 190

Pressure Plate
Part #:D255689
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Flywheel Step - 1.437"
 Stage -Single

 7" CAST ID
 CAN USE IN PLACE OF 6" CAST ID

 Models: 190XT

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 190XT

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 190XT

Alignment Tool
Part #:AT 125
 Large Spline - .771 X 17

 Models: 190XT

Pressure Plate
Part #:D255689
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Flywheel Step - 1.437"
 Stage -Single

 7" CAST ID
 CAN USE IN PLACE OF 6" CAST ID

 Models: 200

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 200

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 200


Agco-Allis/Allis-Chalmers/Deutz-Allis
12 INCH - CLUTCH TORQUE LIMITER
Pressure Plate
Part #:D261248
 Casting O.D. - 12"
 Levers - 0
 Springs - 9
 Flywheel Step - 1.437"
 Stage -Single

 Models: 7000

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 7000


Agco-Allis/Allis-Chalmers/Deutz-Allis
12 INCH - CLUTCH TORQUE LIMITER - POWER SHIFT
Pressure Plate
Part #:D269622
 Casting O.D. - 12"
 Levers - 0
 Springs - 12
 Flywheel Step - 1.437
 Stage -Single

 Models: 7010, 7020, 7040, 7060, 8010


Agco-Allis/Allis-Chalmers/Deutz-Allis
12-1/4 INCH - DUAL STAGE
Clutch Kit
Part #:D2094455N KIT
 Includes: 500 0459 00, 6015-2RS, 6304-2RS, AG 11, D2092903, D2094455

 INCLUDES 6 PAD ENGINE DISC

 Models: 6080

Pressure Plate
Part #:D2094455
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018"
 Stage -Dual Stage

 INCLUDES 6 PAD ENGINE DISC

 Models: 6080

Disc
Part #:D2093915
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 Models: 6080

Disc
Part #:D2093915-UL
 Type - Rigid Unlined Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 Models: 6080

Disc
Part #:D2092903
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 6080

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 Models: 6080

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 6080

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: 6080

Pilot Bearing
Part #:6304-2RS
 I.D - .787"
 O.D - 2.047"
 Thickness - .590"

 Models: 6080

Alignment Tool
Part #:AG 11
 Large Spline - 1 3/4" - 16T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.787

 Models: 6080


Agco-Allis/Allis-Chalmers/Deutz-Allis
13 INCH - SINGLE STAGE
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: D21

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: D21

Pressure Plate
Part #:M3797949
Reference #: 133 0280 10
Reference #: 306498
Reference #: 3797949M2
 Casting O.D. - 13"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - 1.660"
 Stage -Single

 Models: LT 75

Disc
Part #:M3618835-HD-7
Reference #: M3618835M1
 Type - Rigid Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 2"
 Thickness - 23

 Models: LT 75

Pressure Plate
Part #:M3797949
Reference #: 133 0280 10
Reference #: 306498
Reference #: 3797949M2
 Casting O.D. - 13"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - 1.660"
 Stage -Single

 Models: LT 90

Disc
Part #:M3618835-HD-7
Reference #: M3618835M1
 Type - Rigid Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 2"
 Thickness - 23

 Models: LT 90

Pressure Plate
Part #:D2214356
Reference #: 133 0220 30
 Type - Diaphragm
 Casting O.D. - 13"
 Levers - Diaphragm
 Springs - Diaphragm
 Hub/Spline - N/A
 Flywheel Step - 1.340"
 Stage -Single

 Models: 5680, 6680, 6690


Agco-Allis/Allis-Chalmers/Deutz-Allis
13 INCH - SPLIT TORQUE
Clutch Kit
Part #:M3701015N KIT
 Includes: 6203-2RS, 8301245, AG 09, M3701011 HD5, M3701015, N1174

 Models: LT 70

Pressure Plate
Part #:M3701015
Reference #: CA-399RB
 Type - Lever
 Casting O.D. - 13"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-5/8" x 25
 Flywheel Step - .130"
 Stage -Single

 Models: LT 70

Disc
Part #:M3701011 HD5
Reference #: 333 0138 10
Reference #: M3701011
 Type - Spring Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 1-1/8"
 Disc Spline - 21

 Models: LT 70

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: LT 70

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: LT 70

Alignment Tool
Part #:AG 09
 Large Spline - 1 5/8" - 25T
 Small Spline - 1 1/8" - 21T
 Pilot Diameter - 0.670

 Models: LT 70

Clutch Kit
Part #:M3701015N KIT
 Includes: 6203-2RS, 8301245, AG 09, M3701011 HD5, M3701015, N1174

 Models: LT 85

Pressure Plate
Part #:M3701015
Reference #: CA-399RB
 Type - Lever
 Casting O.D. - 13"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-5/8" x 25
 Flywheel Step - .130"
 Stage -Single

 Models: LT 85

Disc
Part #:M3701011 HD5
Reference #: 333 0138 10
Reference #: M3701011
 Type - Spring Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 1-1/8"
 Disc Spline - 21

 Models: LT 85

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: LT 85

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: LT 85

Alignment Tool
Part #:AG 09
 Large Spline - 1 5/8" - 25T
 Small Spline - 1 1/8" - 21T
 Pilot Diameter - 0.670

 Models: LT 85

Clutch Kit
Part #:M3701015N KIT
 Includes: 6203-2RS, 8301245, AG 09, M3701011 HD5, M3701015, N1174

 Models: 8745

Pressure Plate
Part #:M3701015
Reference #: CA-399RB
 Type - Lever
 Casting O.D. - 13"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-5/8" x 25
 Flywheel Step - .130"
 Stage -Single

 Models: 8745

Disc
Part #:M3701011 HD5
Reference #: 333 0138 10
Reference #: M3701011
 Type - Spring Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 1-1/8"
 Disc Spline - 21

 Models: 8745

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 8745

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 8745

Alignment Tool
Part #:AG 09
 Large Spline - 1 5/8" - 25T
 Small Spline - 1 1/8" - 21T
 Pilot Diameter - 0.670

 Models: 8745

Clutch Kit
Part #:M3701015N KIT
 Includes: 6203-2RS, 8301245, AG 09, M3701011 HD5, M3701015, N1174

 Models: 8765

Pressure Plate
Part #:M3701015
Reference #: CA-399RB
 Type - Lever
 Casting O.D. - 13"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-5/8" x 25
 Flywheel Step - .130"
 Stage -Single

 Models: 8765

Disc
Part #:M3701011 HD5
Reference #: 333 0138 10
Reference #: M3701011
 Type - Spring Ceramic Button
 Disc O.D - 13"
 Disc Hub Size - 1-1/8"
 Disc Spline - 21

 Models: 8765

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 8765

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: 8765

Alignment Tool
Part #:AG 09
 Large Spline - 1 5/8" - 25T
 Small Spline - 1 1/8" - 21T
 Pilot Diameter - 0.670

 Models: 8765


Agco-Allis/Allis-Chalmers/Deutz-Allis
13 INCH - DUAL DISC
Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9170

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9170

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9170

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9190

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9190

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9190

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9435

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9435

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9455

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9455


Agco-Allis/Allis-Chalmers/Deutz-Allis
13 INCH - DUAL DISC CONVERSION
Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9170

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9170

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9170

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9190

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9190

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9190

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9435

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9435

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9455

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9455


Agco-Allis/Allis-Chalmers/Deutz-Allis
14 INCH - SINGLE STAGE
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 210

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 210

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 Models: 220

Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: 220

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9130

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9130

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9130

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 Models: 9150

Pilot Bearing
Part #:6008-2RS
 I.D - 1.572"
 O.D - 2.775"
 Thickness - .590"

 Models: 9150

Alignment Tool
Part #:AG 33
 Small Spline - 1 3/4" - 27T
 Pilot Diameter - 1.572

 Models: 9150


Agco-Allis/Allis-Chalmers/Deutz-Allis
STEERING BRAKE DISCS
Steering Disc
Part #:70047631
Reference #: AMR-1155
 Description - Fiber
 OD - 11-11/16"
 ID - 8-1/8"
 External Teeth - 57
 FITS MODELS - HD7


Steering Disc
Part #:70044478
Reference #: AMR-1347
 Description - Fiber
 OD - 13-39/64"
 ID - 10-7/64"
 External Teeth - 67
 FITS MODELS - HD5 AND HD6


Steering Disc
Part #:70057375
Reference #: 1355
 Description - Metallic
 OD - 13-39/64"
 ID - 10-7/64"
 External Teeth - 67
 FITS MODELS - CE


Steering Disc
Part #:70233886
 Description - Steel
 OD - 10-1/2"
 ID - 5-3/8"
 Tangs - 6

 .100 Thickness
 FITS MODELS - HD3 AND HD4


Steering Disc
Part #:71003719
 Description - Fiber
 OD - 9.868"
 ID - 4.885"
 Internal Teeth - 25

 .141 Thickness
 FITS MODELS - HD3 AND HD4


Steering Disc
Part #:71010964
Reference #: 9030
 Description - Metallic
 OD - 9.868"
 ID - 4.885"
 Internal Teeth - 25

 .141 Thickness
 FITS MODELS - HD3 AND HD4 (NOT OEM)



Agco-White
Agco-White & Oliver
Disc
Part #:W160971
 Type - Spring Woven
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 19

 Models: 2-70

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 2-70

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 2-70

Disc
Part #:W160971
 Type - Spring Woven
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 19

 Models: 2-78

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 2-78

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 2-78

Disc
Part #:W160971
 Type - Spring Woven
 Disc O.D - 12"
 Disc Hub Size - 1-1/2"
 Disc Spline - 19

 Models: 4-78

Release Bearing
Part #:N1087
Reference #: 2065
Reference #: 832065
Reference #: A2256-1
 ID - 2.062"
 OD - 3.500"
 Thickness - .750"

 Models: 4-78

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 4-78


Avery
9 INCH - SINGLE STAGE
Pressure Plate
Part #:375493
 Casting O.D. - 9"
 Levers - 3
 Springs - 6
 Flywheel Step - 1.188"
 Stage -Single

 Models: Avery

Disc
Part #:M180250
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: Avery

Disc
Part #:M180250 HD4
 Type - Rigid Ceramic
 Disc O.D - 9"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: Avery

Release Bearing
Part #:N1055-A
 ID - 1.872"
 OD - 3.297"
 Thickness - .807"

 Models: Avery


Belarus
13 INCH - SINGLE STAGE
Pressure Plate
Part #:B1601090
 Type - Lever
 Casting O.D. - 12-7/8"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/16" x 16
 Flywheel Step - 1.389"
 Stage -Single

 Models: 500,
502, 505, 520, 522, 525, 530, 532, 560, 562, 570,
572


Belarus
13-3/8 INCH - SINGLE STAGE
Disc
Part #:B900339
 Type - Spring Woven
 Disc O.D - 13-3/8"
 Disc Hub Size - 1-3/8"
 Disc Spline - 12

 Models: 572, 800, 802, 805, 820, 822, 825, 900, 902, 905,
920, 922, 925, 8245, 8311, 8345, 9311, 9345


Bolens
7-1/4 INCH - SINGLE STAGE
Pressure Plate
Part #:K66592
Reference #: 32200-14500
 Type - Lever
 Casting O.D. - 7-1/4"
 Levers - 3
 Springs - 6
 Stage -Single

 1009LB PLATE LOAD

 Models: G152, G154, G172,
G174


Bolens
9 INCH - SINGLE STAGE
Pressure Plate
Part #:M3703705
 Type - SINGLE STAGE
 Casting O.D. - 9"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-3/8" X 19 SPLINE
 Flywheel Step - FLAT - .020" COUNTER STEP
 Stage -SINGLE

 Models: G254 W/LIVE PTO

Disc
Part #:M3703736
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G254 W/LIVE PTO

Disc
Part #:M3703735
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G254 W/LIVE PTO

Disc
Part #:M3703735 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G254 W/LIVE PTO

Disc
Part #:M3703735 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G254 W/LIVE PTO

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: G254 W/LIVE PTO

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: G254 W/LIVE PTO

Pressure Plate
Part #:M3703705
 Type - SINGLE STAGE
 Casting O.D. - 9"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-3/8" X 19 SPLINE
 Flywheel Step - FLAT - .020" COUNTER STEP
 Stage -SINGLE

 Models: G274 W/LIVE PTO

Disc
Part #:M3703736
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G274 W/LIVE PTO

Disc
Part #:M3703735
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G274 W/LIVE PTO

Disc
Part #:M3703735 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G274 W/LIVE PTO

Disc
Part #:M3703735 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: G274 W/LIVE PTO

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: G274 W/LIVE PTO

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: G274 W/LIVE PTO


Branson
9 INCH - DUAL STAGE
Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 2810

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 2810


Branson
9-1/4 INCH - DUAL STAGE
Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 2629

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2629

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 2800

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2800

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 2810

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2810

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 3520

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3520

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 3638

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3638

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 3820

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3820

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 4020

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4020

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 4220

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4220

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 4520

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4520

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 4720

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4720

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 5530

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 5530

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 Models: 6530

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 6530


Branson
10-1/4 INCH - SINGLE STAGE
Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 2910, 2910I, 3110I

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3110I

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 3120R

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3120R

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 3510

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3510

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 3510I

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3510I

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 3520R

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3520R

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 3820I, 4020R

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4020R

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 4220I, 4520

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4520

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 4720I

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 4720I

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 5220C

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 5220C

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 5220R

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 5220R

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: AC38910

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: AC38910

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: PR25C

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: PR25C

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: PR25R

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: PR25R


Branson
11 INCH - SINGLE STAGE
Pressure Plate
Part #:K112511
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - .025
 Stage -Single
 12-1/4" Hole Center To Center

 Models: 5530

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 5530

Pressure Plate
Part #:K112511
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - .025
 Stage -Single
 12-1/4" Hole Center To Center

 Models: 6530

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: 6530


Case
8-1/2" - DUAL DISC #1
Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: 300


Case
8-1/2" - DUAL DISC #2
Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: 300B Series, 310


Case
9 INCH - SINGLE STAGE
Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: VA, VAC, VAH, VAI, VAO,
VAS


Case
9 INCH - HAND CLUTCH
Disc
Part #:FNA50A
Reference #: 280604
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 1-3/8"
 Disc Spline - 10

 Models: S

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: S

Disc
Part #:FNA50A
Reference #: 280604
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 1-3/8"
 Disc Spline - 10

 Models: SC

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: SC

Disc
Part #:FNA50A
Reference #: 280604
 Type - Spring Woven
 Disc O.D - 9"
 Disc Hub Size - 1-3/8"
 Disc Spline - 10

 Models: SO

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: SO


Case
9-1/4 INCH - SINGLE STAGE #1
Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: 200B Series, 300, 320


Case
9-1/4 INCH - SINGLE STAGE #2
Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 300B Series

Release Bearing
Part #:N906
Reference #: 832135
 ID - 2.123
 OD - 3.506
 Thickness - .895"

 VERIFY DIMENSIONS BEFORE ORDERING
 REPLACES TX990423

 Models: 300B Series

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 310B Series

Release Bearing
Part #:N906
Reference #: 832135
 ID - 2.123
 OD - 3.506
 Thickness - .895"

 VERIFY DIMENSIONS BEFORE ORDERING
 REPLACES TX990423

 Models: 310B Series


Case
9-1/4 INCH - SINGLE STAGE #3
Disc
Part #:A11079
 Type - RIGID
 Disc O.D - 9-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW
 VERIFY HUB SIZE

 Models: 420, 430, 441, 530


Case
10 INCH - SINGLE STAGE #1

Part #:A45790

 Models: 300

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 300

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 300


Part #:A45790

 Models: 300B Series

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 300B Series

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 300B Series


Part #:A45790

 Models: 310

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 310

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 310


Part #:A45790

 Models: 310B Series

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 310B Series

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 310B Series


Case
10 INCH - SINGLE STAGE #2

Part #:A45790

 NO HUB

 Models: 420

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW

 Models: 420

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 420


Part #:A45790

 NO HUB

 Models: 430

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW

 Models: 430

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 430


Part #:A45790

 NO HUB

 Models: 441

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW

 Models: 441

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 441


Part #:A45790

 NO HUB

 Models: 511B

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW

 Models: 511B

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 511B


Part #:A45790

 NO HUB

 Models: 530

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 S/N 8191146 & BELOW

 Models: 530

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 530


Case
10 INCH - SINGLE STAGE #3

Part #:A45790

 NO HUB

 Models: 611B

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 611B

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: 611B


Part #:A45790

 NO HUB

 Models: 630

Disc
Part #:A36145
 Type - Rigid Woven
 Disc O.D - 10'
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 630

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 Models: 630


Case
10 INCH - DUAL STAGE
Disc
Part #:AK923374
 Type - Rigid Woven
 Disc O.D - 10"
 Disc Hub Size - 1-3/4"
 Disc Spline - 10

 USE FOR 325 0077 50

 Models: 380

Disc
Part #:AK 89322
 Type - Rigid Woven
 Disc O.D - 10"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 USE FOR 325 0076 50

 Models: 380


Part #:500 0360 40
Reference #: K620153
 ID - 2.750"
 OD - 4.060"
 Thickness - 0.865"

 Models: 380

Pilot Bearing
Part #:410 0023 00
 I.D - .875"
 O.D - 2.000"
 Thickness - .560"

 Models: 380


Case
11 INCH - 24 SPLINE IPTO
Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 420

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 420


Part #:A36414

 S/N 8297800 & BELOW

 Models: 420


Part #:A36142

 S/N 8297800 & BELOW

 Models: 420

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 420

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 430

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 430


Part #:A36414

 S/N 8297800 & BELOW

 Models: 430


Part #:A36142

 S/N 8297800 & BELOW

 Models: 430

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 430

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 440

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 440


Part #:A36414

 S/N 8297800 & BELOW

 Models: 440


Part #:A36142

 S/N 8297800 & BELOW

 Models: 440

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 440

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 441

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 441


Part #:A36414

 S/N 8297800 & BELOW

 Models: 441


Part #:A36142

 S/N 8297800 & BELOW

 Models: 441

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 441

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 510B

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 510B


Part #:A36414

 S/N 8297800 & BELOW

 Models: 510B


Part #:A36142

 S/N 8297800 & BELOW

 Models: 510B

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 510B

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 511B

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 511B


Part #:A36414

 S/N 8297800 & BELOW

 Models: 511B


Part #:A36142

 S/N 8297800 & BELOW

 Models: 511B

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 511B

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 520

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 520


Part #:A36414

 S/N 8297800 & BELOW

 Models: 520


Part #:A36142

 S/N 8297800 & BELOW

 Models: 520

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 520

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 530

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 530


Part #:A36414

 S/N 8297800 & BELOW

 Models: 530


Part #:A36142

 S/N 8297800 & BELOW

 Models: 530

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 530

Pressure Plate
Part #:A36962
 Levers - 3
 Springs - 6
 Hub/Spline - 1-1/2" X 24
 Stage -SINGLE

 S/N 8297800 & BELOW

 Models: 630

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308
 NO HUB

 Models: 630


Part #:A36414

 S/N 8297800 & BELOW

 Models: 630


Part #:A36142

 S/N 8297800 & BELOW

 Models: 630

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY DIMENSIONS BEFORE ORDERING

 Models: 630


Case
11 INCH - 29 SPLINE IPTO
Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 420

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 420

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 420

Pilot Bearing
Part #:6006-2RS

 Models: 420

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 430

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 430

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 430

Pilot Bearing
Part #:6006-2RS

 Models: 430

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 440

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 440

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 440

Pilot Bearing
Part #:6006-2RS

 Models: 440

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 441

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 441

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 441

Pilot Bearing
Part #:6006-2RS

 Models: 441

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 470

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 470

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 470

Pilot Bearing
Part #:6006-2RS

 Models: 470

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 480

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 480

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 480

Pilot Bearing
Part #:6006-2RS

 Models: 480

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 530

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 530

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 530

Pilot Bearing
Part #:6006-2RS

 Models: 530

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 570

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 570

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 570

Pilot Bearing
Part #:6006-2RS

 Models: 570

Pressure Plate
Part #:A39212
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-7/8" x 29
 Flywheel Step - Flat
 Stage -Single

 S/N 8297801 - 8656925
 USE FOR A37566

 Models: 580

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 580

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 580

Pilot Bearing
Part #:6006-2RS

 Models: 580


Case
11 INCH - NO IPTO W/17 SPLINE DISC
Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 420


Part #:A36414

 S/N 8297800 & BELOW

 Models: 420


Part #:A36142

 Models: 420

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 420

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 430


Part #:A36414

 S/N 8297800 & BELOW

 Models: 430


Part #:A36142

 Models: 430

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 430

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 440


Part #:A36414

 S/N 8297800 & BELOW

 Models: 440


Part #:A36142

 Models: 440

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 440

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 441


Part #:A36414

 S/N 8297800 & BELOW

 Models: 441


Part #:A36142

 Models: 441

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 441

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 510B


Part #:A36414

 S/N 8297800 & BELOW

 Models: 510B


Part #:A36142

 Models: 510B

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 510B

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 520


Part #:A36414

 S/N 8297800 & BELOW

 Models: 520


Part #:A36142

 Models: 520

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 520

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 530


Part #:A36414

 S/N 8297800 & BELOW

 Models: 530


Part #:A36142

 Models: 530

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 530

Pressure Plate
Part #:D1163702
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Flywheel Step - Flat
 Stage -Single

 INTERCHANGEABLE WITH D1145308

 Models: 630


Part #:A36414

 S/N 8297800 & BELOW

 Models: 630


Part #:A36142

 Models: 630

Release Bearing
Part #:N1136-A
Reference #: 1752
Reference #: 831752
Reference #: A0899-2
 ID - 1.752
 OD - 3.060"
 Thickness - .745"

 VERIFY BEARING SIZE BEFORE ORDERING

 Models: 630


Case
11 INCH - NO IPTO W/21 SPLINE DISC
Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 420

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 420

Pilot Bearing
Part #:6006-2RS

 Models: 420

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 430

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 430

Pilot Bearing
Part #:6006-2RS

 Models: 430

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 440

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 440

Pilot Bearing
Part #:6006-2RS

 Models: 440

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 441

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 441

Pilot Bearing
Part #:6006-2RS

 Models: 441

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 470

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 470

Pilot Bearing
Part #:6006-2RS

 Models: 470

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 480

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 480

Pilot Bearing
Part #:6006-2RS

 Models: 480

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 530

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 530

Pilot Bearing
Part #:6006-2RS

 Models: 530

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 570

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 570

Pilot Bearing
Part #:6006-2RS

 Models: 570

Disc
Part #:A51840
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 21

 USE FOR A39087

 Models: 580

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 580

Pilot Bearing
Part #:6006-2RS

 Models: 580


Case
11 INCH - HAND CLUTCH #1
Pilot Bearing
Part #:6205-2RS
 I.D - .984"
 O.D - 2.047"
 Thickness - .590"

 Models: D, DC


Case
12 INCH - SINGLE STAGE #1
Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 380B

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 380B

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 380B

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 380B

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 380B

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 380B


Case
12 INCH - SINGLE STAGE #2
Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 400

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 400

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 411B

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 411B

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 700

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 700

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 730

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 730

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 770

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 770

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 800

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 800

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 811B

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 811B

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 830

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 830

Release Bearing
Part #:N1171
Reference #: 2255-18
Reference #: 8225518
Reference #: AT17464
 ID - 2.250"
 OD - 3.750
 Thickness - 0.750"

 USE FOR 8225518

 Models: 870

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 870


Case
14 INCH - SINGLE STAGE
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 970


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 970

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 970


Case
15 INCH - SINGLE STAGE #1
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1030


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1030

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1030

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1070


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1070

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1070

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1090


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1090

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1090

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1170


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1170

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1170

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1175


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1175

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1175

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1200


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1200

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1200

Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1470


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 1470

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 Models: 1470


Case
15 INCH - SINGLE STAGE #2
Release Bearing
Part #:N1174
Reference #: 2505-T
Reference #: 832505
Reference #: A2287-31
 ID - 2.500"
 OD - 4.154"
 Thickness - .865"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 930


Part #:8369789

 NOTE BEARING SIZE BEFORE ORDERING

 Models: 930

Pilot Bearing
Part #:6007-2RS
 I.D - 1.371"
 O.D - 2.441"
 Thickness - .550"

 LATE
 NOTE BEARING SIZE BEFORE ORDERING

 Models: 930

Pilot Bearing
Part #:6206-2RS
 I.D - 1.181"
 O.D - 2.440"
 Thickness - .630"

 EARLY
 NOTE BEARING SIZE BEFORE ORDERING

 Models: 930


Case-IH
7-1/4 INCH - SINGLE STAGE #1
Clutch Kit
Part #:1273243N KIT-ALLIS-2
 Includes: 1273242, 1273243

 Models: 234

Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 234

Disc
Part #:1273242
 Type - Spring Organic
 Disc O.D - 7-1/4"
 Disc Hub Size - 3/4"
 Disc Spline - 10

 Models: 234

Release Bearing
Part #:N3809

 Models: 234

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 234

Clutch Kit
Part #:1273243N KIT-ALLIS-2
 Includes: 1273242, 1273243

 Models: 235

Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 235

Disc
Part #:1273242
 Type - Spring Organic
 Disc O.D - 7-1/4"
 Disc Hub Size - 3/4"
 Disc Spline - 10

 Models: 235

Release Bearing
Part #:N3809

 Models: 235

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 235


Case-IH
7-1/4 INCH - SINGLE STAGE #2
Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: DX24

Disc
Part #:W111309
 Type - Spring Woven
 Disc O.D - 7-1/4"
 Disc Hub Size - 13/16"
 Disc Spline - 18

 Models: DX24

Release Bearing
Part #:N3774
Reference #: 832102
Reference #: N2102
 ID - 1.496
 OD - 2.642
 Thickness - .640

 Models: DX24

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX24

Pressure Plate
Part #:1273243
Reference #: 37150-14500
 Type - Diaphragm
 Casting O.D. - 7-1/4"
 Levers - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: DX26

Disc
Part #:W111309
 Type - Spring Woven
 Disc O.D - 7-1/4"
 Disc Hub Size - 13/16"
 Disc Spline - 18

 Models: DX26

Release Bearing
Part #:N3774
Reference #: 832102
Reference #: N2102
 ID - 1.496
 OD - 2.642
 Thickness - .640

 Models: DX26

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX26


Case-IH
8 INCH - SINGLE STAGE #1
Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 244

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 244

Release Bearing
Part #:N3809

 Models: 244

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 244

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 245

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 245

Release Bearing
Part #:N3809

 Models: 245

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 245

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 254

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 254

Release Bearing
Part #:N3809

 Models: 254

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 254

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 255

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 255

Release Bearing
Part #:N3809

 Models: 255

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 255

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 265

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 265

Release Bearing
Part #:N3809

 Models: 265

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 265

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 1120

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 1120

Release Bearing
Part #:N3809

 Models: 1120

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1120

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 1130

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 1130

Release Bearing
Part #:N3809

 Models: 1130

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1130

Pressure Plate
Part #:1273254
Reference #: 6C040-13300
Reference #: 973728
 Type - Diaphragm
 Casting O.D. - 8"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: 1140

Disc
Part #:1273253
 Type - SPRING WOVEN
 Disc O.D - 8"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 Models: 1140

Release Bearing
Part #:N3809

 Models: 1140

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1140


Case-IH
8-1/2 INCH - SINGLE STAGE #1
Pressure Plate
Part #:K32430
Reference #: K32430-14500
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Flywheel Step - .630"
 Stage -Single

 9" PPA REPLACES 8-1/2" DIAPHRAGM
 S/N 17657690 & ABOVE

 Models: 275

Disc
Part #:1961930
 Type - Spring Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 13/16"
 Disc Spline - 12

 FITS ALL SERIAL NUMBERS

 Models: 275

Release Bearing
Part #:N3764
 ID - 1.771"
 OD - 2.900"
 Thickness - .700"

 Models: 275

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 275


Case-IH
8-1/2 INCH - SINGLE STAGE #2
Clutch Kit
Part #:FD450011N KIT
Reference #: SBA320450011K
 Includes: 6001-2RS, AG 01, FD320021, FD450011, N3764

 Models: D25

Clutch Kit
Part #:FD450011N CB6 KIT
 Includes: 6001-2RS, AG 01, FD320021 HD6, FD450011, N3764

 Models: D25

Pressure Plate
Part #:FD450011
Reference #: 165317
Reference #: SBA320450011
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - 3
 Flywheel Step - Flat
 Stage -Single

 Models: D25

Disc
Part #:FD320021
Reference #: CD-3940
Reference #: F400261
Reference #: FD320250
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: D25

Disc
Part #:FD320021 HD6
Reference #: CD-3940-CB
Reference #: F400261-CB
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: D25

Release Bearing
Part #:N3764
 ID - 1.771"
 OD - 2.900"
 Thickness - .700"

 Models: D25

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D25

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: D25

Clutch Kit
Part #:FD450011N KIT
Reference #: SBA320450011K
 Includes: 6001-2RS, AG 01, FD320021, FD450011, N3764

 Models: D29

Clutch Kit
Part #:FD450011N CB6 KIT
 Includes: 6001-2RS, AG 01, FD320021 HD6, FD450011, N3764

 Models: D29

Pressure Plate
Part #:FD450011
Reference #: 165317
Reference #: SBA320450011
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - 3
 Flywheel Step - Flat
 Stage -Single

 Models: D29

Disc
Part #:FD320021
Reference #: CD-3940
Reference #: F400261
Reference #: FD320250
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: D29

Disc
Part #:FD320021 HD6
Reference #: CD-3940-CB
Reference #: F400261-CB
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: D29

Release Bearing
Part #:N3764
 ID - 1.771"
 OD - 2.900"
 Thickness - .700"

 Models: D29

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D29

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: D29

Clutch Kit
Part #:FD450011N KIT
Reference #: SBA320450011K
 Includes: 6001-2RS, AG 01, FD320021, FD450011, N3764

 Models: DX25

Clutch Kit
Part #:FD450011N CB6 KIT
 Includes: 6001-2RS, AG 01, FD320021 HD6, FD450011, N3764

 Models: DX25

Pressure Plate
Part #:FD450011
Reference #: 165317
Reference #: SBA320450011
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - 3
 Flywheel Step - Flat
 Stage -Single

 Models: DX25

Disc
Part #:FD320021
Reference #: CD-3940
Reference #: F400261
Reference #: FD320250
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: DX25

Disc
Part #:FD320021 HD6
Reference #: CD-3940-CB
Reference #: F400261-CB
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: DX25

Release Bearing
Part #:N3764
 ID - 1.771"
 OD - 2.900"
 Thickness - .700"

 Models: DX25

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX25

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: DX25

Clutch Kit
Part #:FD450011N KIT
Reference #: SBA320450011K
 Includes: 6001-2RS, AG 01, FD320021, FD450011, N3764

 Models: DX29

Clutch Kit
Part #:FD450011N CB6 KIT
 Includes: 6001-2RS, AG 01, FD320021 HD6, FD450011, N3764

 Models: DX29

Pressure Plate
Part #:FD450011
Reference #: 165317
Reference #: SBA320450011
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - 3
 Flywheel Step - Flat
 Stage -Single

 Models: DX29

Disc
Part #:FD320021
Reference #: CD-3940
Reference #: F400261
Reference #: FD320250
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: DX29

Disc
Part #:FD320021 HD6
Reference #: CD-3940-CB
Reference #: F400261-CB
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: DX29

Release Bearing
Part #:N3764
 ID - 1.771"
 OD - 2.900"
 Thickness - .700"

 Models: DX29

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX29

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: DX29


Case-IH
8-1/2 INCH - DUAL STAGE #1
Disc
Part #:1992563
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 USE FOR M3438913
 ENGINE DISC

 Models: 1120

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 1120

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1120

Disc
Part #:1992563
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 USE FOR M3438913
 ENGINE DISC

 Models: 1130

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 1130

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1130

Disc
Part #:1992563
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 USE FOR M3438913
 ENGINE DISC

 Models: 1140

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 1140

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 1140


Case-IH
8-1/2 INCH - DUAL STAGE #2
Pressure Plate
Part #:FD320693
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-3/8" x 19
 Flywheel Step - .125"
 Stage -Dual

 Models: D29

Disc
Part #:FD320021 HD6
Reference #: CD-3940-CB
Reference #: F400261-CB
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: D29

Disc
Part #:FD320260
Reference #: K36260-14450
Reference #: TD060-20500
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 PTO DISC

 Models: D29

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: D29

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D29

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: D29

Disc
Part #:FD320021
Reference #: CD-3940
Reference #: F400261
Reference #: FD320250
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 LONG END OF HUB INSTALLS TOWARDS THE TRANSMISSION

 Models: DX29


Case-IH
9 INCH - SINGLE STAGE #1
Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: D33

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: D33

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: D33

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: D33

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: D33

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: D33

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D33

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: D33

Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: DX31

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: DX31

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: DX31

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX31

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX31

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: DX31

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX31

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: DX31

Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: DX33

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: DX33

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: DX33

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX33

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX33

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: DX33

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX33

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: DX33

Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: DX34

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: DX34

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: DX34

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX34

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: DX34

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: DX34

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX34

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: DX34

Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: Farmall 31

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: Farmall 31

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: Farmall 31

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: Farmall 31

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: Farmall 31

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 31

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 31

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: Farmall 31

Clutch Kit
Part #:FD320230N KIT
 Includes: 6001-2RS, AG 01, FD320230, FD320530, N018

 Models: Farmall 35

Clutch Kit
Part #:FD320230N KIT-2
 Includes: FD320230, FD320530

 Models: Farmall 35

Pressure Plate
Part #:FD320230
 Type - Diaphragm
 Casting O.D. - 9"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 Models: Farmall 35

Disc
Part #:FD320530
 Type - Rigid Woven
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: Farmall 35

Disc
Part #:FD320530 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 Models: Farmall 35

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 35

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 35

Alignment Tool
Part #:AG 01
 Large Spline - 1 3/8" - 19T
 Small Spline - 15/16" - 10T
 Pilot Diameter - 0.468

 Models: Farmall 35


Case-IH
9-1/2 INCH - SINGLE STAGE #1
Clutch Kit
Part #:K20206N-FORD KIT
 Includes: 6001-2RS, FD320560, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
 05-01-2001 & LATER

 Models: D35

Clutch Kit
Part #:K20206N-FORD CB KIT
 Includes: 6001-2RS, FD320560 HD4, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
  05-01-2001 & LATER

 Models: D35

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: D35

Disc
Part #:FD320560
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D35

Disc
Part #:FD320560 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D35

Disc
Part #:FD320560 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D35

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 05-01-2001 & LATER

 Models: D35

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 4-30-2001 & EARLIER

 Models: D35

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D35

Clutch Kit
Part #:K20206N-FORD KIT
 Includes: 6001-2RS, FD320560, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
 05-01-2001 & LATER

 Models: D40

Clutch Kit
Part #:K20206N-FORD CB KIT
 Includes: 6001-2RS, FD320560 HD4, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
  05-01-2001 & LATER

 Models: D40

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: D40

Disc
Part #:FD320560
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D40

Disc
Part #:FD320560 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D40

Disc
Part #:FD320560 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D40

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 05-01-2001 & LATER

 Models: D40

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 4-30-2001 & EARLIER

 Models: D40

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D40


Case-IH
9-1/2 INCH - SINGLE STAGE #2
Clutch Kit
Part #:K20206N-FORD KIT
 Includes: 6001-2RS, FD320560, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
 S/N 3M19775

 Models: DX35

Clutch Kit
Part #:K20206N-FORD CB KIT
 Includes: 6001-2RS, FD320560 HD4, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING

 Models: DX35

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: DX35

Disc
Part #:FD320560
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: DX35

Disc
Part #:FD320560 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: DX35

Disc
Part #:FD320560 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: DX35

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 NOTE BEARING SIZE BEFORE ORDERING
 S/N 3M19775

 Models: DX35

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: DX35

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX35

Clutch Kit
Part #:K20206N-FORD KIT
 Includes: 6001-2RS, FD320560, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING
 S/N 3M19775

 Models: Farmall 40

Clutch Kit
Part #:K20206N-FORD CB KIT
 Includes: 6001-2RS, FD320560 HD4, K20206, N018

 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 40

Pressure Plate
Part #:K20206
Reference #: K31301-14600
Reference #: KTA020-20600
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 40

Disc
Part #:FD320560
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 40

Disc
Part #:FD320560 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 40

Disc
Part #:FD320560 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 40

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 NOTE BEARING SIZE BEFORE ORDERING
 S/N 3M19775

 Models: Farmall 40

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 40

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 40


Case-IH
9-1/2 INCH - SINGLE STAGE #3
Pressure Plate
Part #:R127827
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 30B

Disc
Part #:MO1250107
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 22

 Models: Farmall 30B

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 30B

Pressure Plate
Part #:R127827
 Type - Diaphragm
 Casting O.D. - 9-1/2"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 35B

Disc
Part #:MO1250107
 Type - Spring Woven
 Disc O.D - 9-1/2"
 Disc Hub Size - 1-3/16"
 Disc Spline - 22

 Models: Farmall 35B

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 35B


Case-IH
10-1/4 INCH - SINGLE STAGE #1
Pressure Plate
Part #:K40206
 Type - Diaphragm
 Casting O.D. - 10-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: D45

Disc
Part #:FD320570
 Type - Spring Woven
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D45

Disc
Part #:FD320570 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: D45

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 5/1/2001 & AFTER

 Models: D45

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 4/30/2001 & BEFORE

 Models: D45

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: D45


Case-IH
10-1/4 INCH - SINGLE STAGE #2
Pressure Plate
Part #:K40206
 Type - Diaphragm
 Casting O.D. - 10-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 45

Disc
Part #:FD320570
 Type - Spring Woven
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 45

Disc
Part #:FD320570 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 45

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 45

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 45

Pressure Plate
Part #:K40206
 Type - Diaphragm
 Casting O.D. - 10-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 50

Disc
Part #:FD320570
 Type - Spring Woven
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 50

Disc
Part #:FD320570 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 10-1/4"
 Disc Hub Size - 1-3/16"
 Disc Spline - 16

 Models: Farmall 50

Release Bearing
Part #:N018
Reference #: 832103
Reference #: TK45-4B
 ID - 1.771"
 OD - 2.900"
 Thickness - 0.700"

 Models: Farmall 50

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 50


Case-IH
11 INCH - SINGLE STAGE #1
Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 380B

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 380B

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 380B

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 380B

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 380B

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 380B

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 385

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 385

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 385

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 385

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 385

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 385

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 395

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 395

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 395

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 395

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 395

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 395

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 485

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 485

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 485

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 485

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 485

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 485

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 495

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 495

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 495

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 495

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 495

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 495

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 585

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 585

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 585

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 585

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 585

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 585

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 595

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 595

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 595

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 595

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 595

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 595

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 3220

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 3220

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3220

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3220

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3220

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3220

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 3400

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 3400

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3400

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3400

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3400

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3400

Clutch Kit
Part #:70716N KIT
 Includes: 12" KRAFT BOX, 2375-F, 6204-2RS, 70093, 70716, AG 02

 Models: 3434

Pressure Plate
Part #:70716
Reference #: 1994425C1
Reference #: 68211C91
 Type - Lever
 Casting O.D. - 11"
 Levers - 3
 Springs - 6
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.443"
 Stage -Single

 Models: 3434

Disc
Part #:70093
Reference #: 1944253C1
Reference #: 70093C91
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3434

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3434

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3434

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3434


Case-IH
11 INCH - SINGLE STAGE #2
Clutch Kit
Part #:FD450310N KIT
 Includes: 6001-2RS, FD320650, FD450310, RCT55B

 Models: DX48

Clutch Kit
Part #:FD450310-CBN-KIT
 Includes: 15" KRAFT BOX, 6001-2RS, FD320650 HD6, FD450310, RCT55B

 Models: DX48

Clutch Kit
Part #:FD450310N-R KIT
 Includes: 6001-2RS, FD320651, FD450310, RCT55B

 Models: DX48

Pressure Plate
Part #:FD450310
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: DX48

Disc
Part #:FD320650
 Type - Spring Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX48

Disc
Part #:FD320650 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX48

Disc
Part #:FD320651
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX48

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: DX48

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX48

Clutch Kit
Part #:FD450310N KIT
 Includes: 6001-2RS, FD320650, FD450310, RCT55B

 Models: DX55

Clutch Kit
Part #:FD450310-CBN-KIT
 Includes: 15" KRAFT BOX, 6001-2RS, FD320650 HD6, FD450310, RCT55B

 Models: DX55

Clutch Kit
Part #:FD450310N-R KIT
 Includes: 6001-2RS, FD320651, FD450310, RCT55B

 Models: DX55

Pressure Plate
Part #:FD450310
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: DX55

Disc
Part #:FD320650
 Type - Spring Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX55

Disc
Part #:FD320650 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX55

Disc
Part #:FD320651
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: DX55

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: DX55

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: DX55

Clutch Kit
Part #:FD450310N KIT
 Includes: 6001-2RS, FD320650, FD450310, RCT55B

 Models: Farmall 55

Clutch Kit
Part #:FD450310-CBN-KIT
 Includes: 15" KRAFT BOX, 6001-2RS, FD320650 HD6, FD450310, RCT55B

 Models: Farmall 55

Clutch Kit
Part #:FD450310N-R KIT
 Includes: 6001-2RS, FD320651, FD450310, RCT55B

 Models: Farmall 55

Pressure Plate
Part #:FD450310
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 55

Disc
Part #:FD320650
 Type - Spring Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 55

Disc
Part #:FD320650 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 55

Disc
Part #:FD320651
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 55

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: Farmall 55

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 55

Clutch Kit
Part #:FD450310N KIT
 Includes: 6001-2RS, FD320650, FD450310, RCT55B

 Models: Farmall 60

Clutch Kit
Part #:FD450310-CBN-KIT
 Includes: 15" KRAFT BOX, 6001-2RS, FD320650 HD6, FD450310, RCT55B

 Models: Farmall 60

Clutch Kit
Part #:FD450310N-R KIT
 Includes: 6001-2RS, FD320651, FD450310, RCT55B

 Models: Farmall 60

Pressure Plate
Part #:FD450310
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 60

Disc
Part #:FD320650
 Type - Spring Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 60

Disc
Part #:FD320650 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 60

Disc
Part #:FD320651
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 60

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: Farmall 60

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 60

Clutch Kit
Part #:FD450310N KIT
 Includes: 6001-2RS, FD320650, FD450310, RCT55B

 Models: Farmall 70

Clutch Kit
Part #:FD450310-CBN-KIT
 Includes: 15" KRAFT BOX, 6001-2RS, FD320650 HD6, FD450310, RCT55B

 Models: Farmall 70

Clutch Kit
Part #:FD450310N-R KIT
 Includes: 6001-2RS, FD320651, FD450310, RCT55B

 Models: Farmall 70

Pressure Plate
Part #:FD450310
 Type - Diaphragm
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 70

Disc
Part #:FD320650
 Type - Spring Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 70

Disc
Part #:FD320650 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 70

Disc
Part #:FD320651
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 70

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: Farmall 70

Pilot Bearing
Part #:6001-2RS
 I.D - 0.475"
 O.D - 1.102"
 Thickness - 0.313

 Models: Farmall 70


Case-IH
11 INCH - SINGLE STAGE #3
Pressure Plate
Part #:K32530
Reference #: 3A481-25110
Reference #: SC32232
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 40B

Disc
Part #:M01250067
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 40B

Disc
Part #:M01250067 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 40B

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: Farmall 40B

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: Farmall 40B

Pressure Plate
Part #:K32530
Reference #: 3A481-25110
Reference #: SC32232
 Casting O.D. - 11"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - Flat
 Stage -Single

 Models: Farmall 50B

Disc
Part #:M01250067
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 50B

Disc
Part #:M01250067 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-3/8"
 Disc Spline - 19

 Models: Farmall 50B

Release Bearing
Part #:RCT55B
Reference #: 835582
 ID - 2.166"
 OD - 3.468"
 Thickness - 0.866"

 Models: Farmall 50B

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: Farmall 50B


Case-IH
11 INCH - SINGLE STAGE - HEAVY DUTY #1
Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 380B

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 380B

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 380B

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 380B

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 385

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 385

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 385

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 385

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 395

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 395

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 395

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 395

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 485

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 485

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 485

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 485

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 495

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 495

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 495

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 495

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 585

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 585

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 585

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 585

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 595

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 595

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 595

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 595

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 3220

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3220

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3220

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3220

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 3400

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3400

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3400

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3400

Pressure Plate
Part #:830574
 Type - Lever
 Levers - 3
 Springs - 9
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - 1.443"

 Models: 3434

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3434

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3434

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3434


Case-IH
11 INCH - DUAL STAGE #1
Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJ55

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJ55

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJ55

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJ55

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJ65

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJ65

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJ65

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJ65

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJ75

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJ75

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJ75

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJ75

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJN55

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJN55

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJN55

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJN55

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJN65

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJN65

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJN65

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJN65

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJN75

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJN75

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJN75

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJN75

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJV55

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJV55

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJV55

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJV55

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJV65

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJV65

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJV65

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJV65

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: PJV75

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: PJV75

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: PJV75

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: PJV75

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: 2120

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 2120

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 2120

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 2120

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: 2130

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 2130

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 2130

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 2130

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: 2140

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 2140

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 2140

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 2140

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: 2150

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: 2150

Pilot Bearing
Part #:6013-2RS
Reference #: 830166
 I.D - 2.557"
 O.D - 3.936"
 Thickness - 0.704"

 PTO BEARING

 Models: 2150

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: 2150


Case-IH
11 INCH - DUAL STAGE #2
Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 60

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 60

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: Farmall 60

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 60

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: Farmall 60

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 60

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 60

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 60

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 60

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 60

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 60

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 60

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 70

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 70

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: Farmall 70

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 70

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: Farmall 70

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 70

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: Farmall 70

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 70

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 70

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 70

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 70

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 70

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX 55

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX 55

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX 55

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX 55

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX 55

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX 55

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX 55

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX 55

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX 55

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX 55

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX 55

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX 55

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX65

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX65

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX65

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX65

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX65

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX65

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX65

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX65

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX65

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX65

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX65

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX65

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX70

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX70

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX70

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX70

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX70

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX70

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX70

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX70

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX70

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX70

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX70

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX70

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX75

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX75

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX75

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX75

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX75

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX75

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX75

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX75

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX75

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX75

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX75

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX75

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX80

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX80

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX80

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX80

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX80

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX80

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX80

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX80

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX80

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX80

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX80

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX80

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX85

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX85

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX85

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX85

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX85

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX85

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX85

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX85

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX85

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX85

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX85

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX85

Clutch Kit
Part #:D2094463N-15/16" KIT
 Includes: 500 0459 00, 6013-2RS, 6303-2RS, AG 29, D2094463, F5176450

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX90

Clutch Kit
Part #:D2094463N KIT
 Includes: 500 0459 00, 6013-2RS, 6014-2RS, 6303-2RS, AG 29, D2091671

 NOTE HUB SIZE BEFORE ORDERING

 Models: JX90

Pressure Plate
Part #:D2094463
Reference #: 228 0077 10
 Type - Lever
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .079
 Stage -Dual

 Models: JX90

Disc
Part #:D272699
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX90

Disc
Part #:D2093949
Reference #: 328 0185 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 INTERCHANGEABLE W/328 0185 10

 Models: JX90

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX90

Disc
Part #:D2091671
 Type - Rigid Woven
 Disc O.D - 11"
 Disc Hub Size - 1"
 Disc Spline - 10

 PTO DISC
 INTERCHANGEABLE W/328 0186 16
 NOTE HUB SIZE BEFORE ORDERING

 Models: JX90

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX90

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX90

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX90


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO - S/N SEPT 2011 & AFTER
Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 65C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 65C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 65C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING

 Models: Farmall 65C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 65C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 65C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 75C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 75C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 75C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING

 Models: Farmall 75C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 75C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 75C


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO #2
Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 45A

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC

 Models: Farmall 45A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 45A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 45A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 45A

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 45A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 45A

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 50A

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC

 Models: Farmall 50A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 50A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 50A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 50A

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 50A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 50A

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 75A

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC

 Models: Farmall 75A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 75A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 75A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 75A

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 75A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 75A


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO #3 - 3/10 - 12/17
Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 55A

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 USE FOR 328 0332 10
 REPLACES 3 PAD PTO DISC

 Models: Farmall 55A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 55A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 55A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 55A

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 55A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 55A


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO #4 - 9/18 & UP
Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 55A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 55A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 55A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: Farmall 55A

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 55A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 55A

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 65A

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 65A

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 65A

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 Models: Farmall 65A

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 65A

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 65A


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO #5
Clutch Kit
Part #:F5181421N 6014 KIT
 Includes: 500 0459 00, 6014-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: Farmall 70

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: Farmall 70

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 70

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 70

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 70

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 70

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 70

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 70

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 70

Clutch Kit
Part #:F5181421N 6014 KIT
 Includes: 500 0459 00, 6014-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: Farmall 80

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: Farmall 80

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 80

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 80

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 80

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 80

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 80

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 80

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 80

Clutch Kit
Part #:F5181421N 6014 KIT
 Includes: 500 0459 00, 6014-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX80

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX80

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX80

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX80

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX80

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX80

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX80

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX80

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX80

Clutch Kit
Part #:F5181421N 6014 KIT
 Includes: 500 0459 00, 6014-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX90

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX90

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX90

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX90

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX90

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX90

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX90


Case-IH
11 INCH - DUAL STAGE W/ SINGLE LEVER PTO #6
Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: Farmall 65C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: Farmall 65C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 65C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 65C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 65C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 65C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 65C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 65C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 65C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: Farmall 75C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: Farmall 75C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 75C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 75C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 75C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 75C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 75C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 75C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 75C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: Farmall 95C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: Farmall 95C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: Farmall 95C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 95C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 95C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 95C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: Farmall 95C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 95C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX60

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX60

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX60

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX60

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX60

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX60

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX60

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX60

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX60

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX70

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX70

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX70

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX70

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX70

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX70

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX70

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX70

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX70

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1060

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1060

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1060

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1060

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1060

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1060

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1060

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1060

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1060

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1060C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1060C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1060C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1060C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1060C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1060C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1060C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1060C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1060C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1070

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1070

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1070

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1070

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1070

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1070

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1070

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1070

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1070C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1070C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1070C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1070C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1070C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1070C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1070C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1070C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1075

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1075

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1075

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1075

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1075

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1075

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1075C

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1075C

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1075C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1075C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1075C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1075C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075C

Clutch Kit
Part #:F5181421N KIT
 Includes: 500 0459 00, 6015-2RS, 6303-2RS, AG 29, F5176450, F5181421

 NOTE PTO BEARING SIZE

 Models: JX1075N

Pressure Plate
Part #:F5181421
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020
 Stage -Dual

 USE FOR 228 0183 10

 Models: JX1075N

Disc
Part #:F5181422
Reference #: 328 0261 10
 Type - Spring Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 ENGINE DISC

 Models: JX1075N

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075N

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1075N

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1075N

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO BEARING
 NOTE BEARING SIZE BEFORE ORDERING

 Models: JX1075N

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075N

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075N


Case-IH
11 INCH - POWERSHIFT
Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: Farmall 65C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: Farmall 65C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: Farmall 65C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 65C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: Farmall 65C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 65C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 65C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: Farmall 70

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: Farmall 70

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: Farmall 70

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 70

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: Farmall 70

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 70

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 70

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: Farmall 75C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: Farmall 75C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: Farmall 75C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 75C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: Farmall 75C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 75C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 75C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: Farmall 95C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: Farmall 95C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: Farmall 95C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 95C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: Farmall 95C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 95C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX60

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX60

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX60

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX60

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX60

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX60

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX60

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1060

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1060

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1060

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1060

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1060

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1060

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1060

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1060C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1060C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1060C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1060C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1060C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1060C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1060C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1070

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1070

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1070

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1070

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1070

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1070

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1070C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1070C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1070C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1070C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1070C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1070C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1075

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1075

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1075

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1075

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1075C

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1075C

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1075C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1075C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075C

Clutch Kit
Part #:F5181427N KIT
 Includes: 6015-2RS, 6303-2RS, AG 29, F5176450, F5181427

 Models: JX1075N

Clutch Kit
Part #:F5181427N KIT-2
 Includes: F5176450, F5181427

 PRESSURE PLATE & DISC ONLY

 Models: JX1075N

Pressure Plate
Part #:F5181427
 Type - Lever Style
 Casting O.D. - 11"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-9/16" x 14
 Flywheel Step - .020"
 Stage -Powershift

 USE FOR 128 0302 10

 Models: JX1075N

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: JX1075N

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 Models: JX1075N

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1075N

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1075N


Case-IH
12 INCH - SINGLE STAGE #1
Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 380B

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 380B

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 380B

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 380B

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 380B

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 380B

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 495

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 495

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 495

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 495

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 495

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 495

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 585

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 585

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 585

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 585

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 585

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 585

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 595

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 595

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 595

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 595

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 595

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 595

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 685

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 685

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 685

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 685

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 685

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 685

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 695

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 695

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 695

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 695

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 695

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 695

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 785

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 785

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 785

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 785

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 785

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 785

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 885

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 885

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 885

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 885

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 885

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 885

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 895

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 895

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 895

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 895

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 895

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 895

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 995

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 995

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 995

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 995

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 995

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 995

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 3220

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 3220

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3220

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3220

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3220

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3220

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 3400

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 3400

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3400

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3400

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3400

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3400

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 3434

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 3434

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 3434

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 3434

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 3434

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 3434

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 4210

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 4210

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 4210

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 4210

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 4210

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 4210

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 4230

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 4230

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 4230

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 4230

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 4230

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 4230

Clutch Kit
Part #:85025N KIT
 Includes: 15" KRAFT BOX, 2375-F, 6204-2RS, 85025, 85026 HD6, AG 02

 Models: 4240

Pressure Plate
Part #:85025
Reference #: 131 0038 10
 Type - Lever
 Casting O.D. - 12"
 Levers - 3
 Springs - 12
 Hub/Spline - 1-5/8" x 10
 Flywheel Step - 1.406"
 Stage -Single

 Models: 4240

Disc
Part #:85026 HD6
 Type - Spring Ceramic Button
 Disc O.D - 12"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: 4240

Release Bearing
Part #:2375-F
 ID - 2.375"
 OD - 3.850"
 Thickness - .810

 Models: 4240

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 4240

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: 4240


Case-IH
12-1/4 INCH - SINGLE STAGE #1
Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 856XL

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: 856XL

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 856XL

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 955XL

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: 955XL

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 955XL

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 956XL

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: 956XL

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 956XL

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 1055XL

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: 1055XL

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 1055XL

Release Bearing
Part #:N063
 ID - 2.560"
 OD - 4.015"
 Thickness - .880"

 Models: 1056XL

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: 1056XL

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: 1056XL


Case-IH
12-1/4 INCH - SINGLE STAGE #3
Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: Farmall 85U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 85U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 85U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: Farmall 95U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 95U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: Farmall 105U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 105U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 105U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX70U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX70U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX70U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX75U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX75U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX75U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX80U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX80U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX80U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX85U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX85U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX85U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX90

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX90U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX90U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX100U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX100U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX100U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX1070U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1070U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX1080U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1080U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1080U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX1090U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1090U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1090U

Pressure Plate
Part #:F5189825
 Type - Diaphragm
 Casting O.D. - 12-1/4"
 Levers - Diaphragm
 Springs - Diaphragm
 Stage -Single

 USE FOR 131 0249 10

 Models: JX1100U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1100U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1100U


Case-IH
12-1/4 INCH - SINGLE STAGE #4
Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C50

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C50

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C50

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C50

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C50

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C50

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C50

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C60

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C60

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C60

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C60

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C60

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C60

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C60

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C70

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C70

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C70

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C70

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C70

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C70

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C70

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C80

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C80

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C80

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C80

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C80

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C80

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C80

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C90

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C90

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C90

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C90

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C90

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C90

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C90

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: C100

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: C100

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: C100

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: C100

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: C100

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: C100

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: C100

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX50

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX50

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX50

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX50

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX50

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX50

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX50

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX60

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX60

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX60

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX60

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX60

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX60

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX60

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX70

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX70

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX70

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX70

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX70

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX70

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX70

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX80

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX80

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX80

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX80

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX80

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX80

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX80

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX90

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX90

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX90

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX90

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX90

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX90

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX90

Clutch Kit
Part #:223807N KIT
 Includes: 15" KRAFT BOX, 223807, 341723, 500 0361 50, 6204-2RS, AG 02

 Models: CX100

Clutch Kit
Part #:223807N KIT-2
 Includes: 223807, 341723

 Models: CX100

Pressure Plate
Part #:223807
 Type - Diaphragm
 Casting O.D. - 12-1/4'
 Levers - N/A
 Springs - Diaphragm
 Hub/Spline - 1-5/8" X 10
 Flywheel Step - Flat
 Stage -Single

 Models: CX100

Disc
Part #:341723
 Type - Spring Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-1/8"
 Disc Spline - 10

 Models: CX100

Release Bearing
Part #:500 0361 50
 ID - 2.374"
 OD - 4.001"
 Thickness - .836"

 DOES NOT INCLUDE THRUST PLATE

 Models: CX100

Pilot Bearing
Part #:6204-2RS
 I.D - .787"
 O.D - 1.850"
 Thickness - .551"

 Models: CX100

Alignment Tool
Part #:AG 02
 Large Spline - 1 5/8" - 10T
 Small Spline - 1 1/8" - 10T
 Pilot Diameter - 0.750

 Models: CX100


Case-IH
12-1/4 INCH - DUAL STAGE #1
Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 95C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 95C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 95C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: Farmall 95C

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 95C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACCES 3 PAD PTO DISC

 Models: Farmall 105C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 105C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 105C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: Farmall 105C

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 105C

Disc
Part #:F5176450
Reference #: 328 0332 10
 Type - Rigid Ceramic Button
 Disc O.D - 11"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 4 PAD CERAMIC BUTTON PTO DISC
 REPLACES 3 PAD PTO DISC

 Models: Farmall 115C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 115C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 115C

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: Farmall 115C

Pilot Bearing
Part #:6203-2RS
 I.D - .6693"
 O.D - 1.5748"
 Thickness - 1.5748"

 Models: Farmall 115C


Case-IH
12-1/4 INCH - DUAL STAGE W/SINGLE LEVER PTO #1
Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 85U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 85U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 85U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 85U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 85U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 85U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 85U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 85U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: Farmall 85U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 85U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 85U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX70U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX70U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX70U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX70U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX70U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX70U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX70U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX70U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: JX70U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX70U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX70U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX80U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX80U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX80U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX80U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX80U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX80U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX80U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX80U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: JX80U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX80U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX80U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX1070U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX1070U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX1070U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1070U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX1070U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX1070U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1070U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1070U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: JX1070U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1070U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1070U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX1080U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX1080U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX1080U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1080U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX1080U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX1080U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1080U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1080U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: JX1080U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1080U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1080U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX1090U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX1090U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX1090U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX1090U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX1090U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX1090U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX1090U

Pilot Bearing
Part #:6015-2RS
Reference #: 500 0400 00
 I.D - 2.952"
 O.D - 4.525"
 Thickness - 0.785"

 PTO RELEASE BEARING

 Models: JX1090U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX1090U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX1090U


Case-IH
12-1/4 INCH - DUAL STAGE W/HYDRAULIC PTO & CAB
Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 105C

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 105C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 105C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 105C

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 105U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 105U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 105U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 105U


Case-IH
12-1/4 INCH - DUAL STAGE W/MECHANICAL PTO W/O CAB
Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 90

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 90

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 90

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 90

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 90

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 90

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 90

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 90

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 90

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 90

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 95

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 95

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 95

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 95

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 95

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 95

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 95

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 95

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 95

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 95

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 95U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 95U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 95U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 95U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 95U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 95U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 95U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 95U

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 95U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 95U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 105C

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 105C

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 105C

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 105C

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 105C

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 105C

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 105C

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 105C

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 105C

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 105C

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 105C

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: Farmall 105U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: Farmall 105U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: Farmall 105U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 105U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 105U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 105U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 105U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 105U

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 105U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 105U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: Farmall 105U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX90

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX90

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX90

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX90

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX90

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX90

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX90

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX90

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX90

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX90U

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX90U

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX90U

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX90U

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX90U

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX90U

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX90U

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX90U

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX90U

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX90U

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX90U

Clutch Kit
Part #:F5189875N KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, AG 60, F5189875

 Models: JX95

Clutch Kit
Part #:F5189875CBN KIT
 Includes: 500 0459 00, 6014-2RS, 6015-2RS, 6303-2RS, F5189875, M3105233-CB

 Models: JX95

Pressure Plate
Part #:F5189875
Reference #: 231 0088 10
 Type - Lever
 Casting O.D. - 12-1/4"
 Levers - 6
 Springs - Belleville
 Hub/Spline - 1-3/4" x 16
 Flywheel Step - .018
 Stage -Dual

 USE FOR 231 0088 10

 Models: JX95

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX95

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX95

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX95

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX95

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX95

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX95

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX95

Alignment Tool
Part #:AG 29
 Large Spline - 1 9/16" - 14T
 Small Spline - 1" - 10T
 Pilot Diameter - 0.667

 Models: JX95


Case-IH
12-1/4 INCH - DUAL STAGE STRADDLE MOUNT CLUTCH
Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 90

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 90

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 90

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 90

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 90

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 90

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 90

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: Farmall 95

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: Farmall 95

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: Farmall 95

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: Farmall 95

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: Farmall 95

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: Farmall 95

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: Farmall 95

Disc
Part #:F5189823
 Type - Spring Ceramic
 Disc O.D - 12-1/4"
 Disc Hub Size - 1-3/4"
 Disc Spline - 16

 USE FOR 331 0219 10

 Models: JX95

Disc
Part #:M3105233
 Type - Rigid Woven
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR 331 0220 10
 USE FOR F5167937

 Models: JX95

Disc
Part #:M3105233-CB
 Type - Rigid Ceramic Button
 Disc O.D - 12-1/4"
 Disc Hub Size - 15/16"
 Disc Spline - 10

 PTO DISC
 USE FOR F5167937-HD6

 Models: JX95

Release Bearing
Part #:500 0459 00
Reference #: 8301080
Reference #: 87345759
Reference #: 87541562
 ID - 1.968"
 OD - 3.550"
 Thickness - 0.845"

 RELEASE BEARING W/COLLAR

 Models: JX95

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 BEARING ONLY W/O COLLAR

 Models: JX95

Pilot Bearing
Part #:6014-2RS
Reference #: 500 0284 00
Reference #: 830114
Reference #: AR27447
 I.D - 2.758"
 O.D - 4.328"
 Thickness - 0.784"

 PTO BEARING

 Models: JX95

Pilot Bearing
Part #:6303-2RS
Reference #: 410 0025 00
 I.D - .669"
 O.D - 1.850"
 Thickness - .550"

 Models: JX95


Case-IH
12-1/4 INCH - SINGLE STAGE - GEAR TOOTH FACING
Twin Discs/Rockford/Gear Rings
Part #:M5579DTD
Reference #: AMS-1251
 OD -12-1/4"
 ID -6-1/4"
 Thickness -7/16"
 Segments -1 PC
 Teeth -72 EXT

 1 - 360 DEGREE SEGMENT

 Models: RP110, RP135, RP165, 4391TA,
6590, 6590T, 6590TA, 6591T, 6830T


Case-IH
13-3/4 INCH - TORSIONAL DAMPER
Disc
Part #:87542609
Reference #: 1866 600 022
Reference #: 370 0032 10
Reference #: D8NN7550AA
 Type - Spring
 Disc O.D - 13-3/4"
 Disc Hub Size - 1-9/16"
 Disc Spline - 14

 8 MOUNTING HOLES

 Models: MXM120, MXM130, MXM140, MXM155, Puma 115, Puma 125,
Puma 130, Puma 140, Puma 145, Puma 155, Puma 160, Puma 165, Puma 180, Puma 195, Puma 210


Case-IH
14 INCH - SINGLE STAGE
Pressure Plate
Part #:F82983566
Reference #: 135 0282 10
 Type - Diaphragm
 Casting O.D. - 14"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - 1.340"
 Stage -Single

  USE FOR 135 0282 10

 Models: Maxxum 115

Release Bearing
Part #:510 0019 10
Reference #: 3182 001 002
Reference #: 471 3444 0
Reference #: 8186 4436
Reference #: FONN-7580 AA

 USE FOR HYDRAULIC CLUTCHES ONLY
 2 PORT
 ONLY USE HYDRAULIC FLUID

 Models: Maxxum 115

Pilot Bearing
Part #:836108
 I.D - 1.440"
 O.D - 2.677"
 Thickness - .590

 Models: Maxxum 115

Pressure Plate
Part #:F82983566
Reference #: 135 0282 10
 Type - Diaphragm
 Casting O.D. - 14"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - 1.340"
 Stage -Single

  USE FOR 135 0282 10

 Models: Maxxum 125

Release Bearing
Part #:510 0019 10
Reference #: 3182 001 002
Reference #: 471 3444 0
Reference #: 8186 4436
Reference #: FONN-7580 AA

 USE FOR HYDRAULIC CLUTCHES ONLY
 2 PORT
 ONLY USE HYDRAULIC FLUID

 Models: Maxxum 125

Pilot Bearing
Part #:836108
 I.D - 1.440"
 O.D - 2.677"
 Thickness - .590

 Models: Maxxum 125

Pressure Plate
Part #:F82983566
Reference #: 135 0282 10
 Type - Diaphragm
 Casting O.D. - 14"
 Levers - Diaphragm
 Springs - Diaphragm
 Flywheel Step - 1.340"
 Stage -Single

  USE FOR 135 0282 10

 Models: MXU115

Release Bearing
Part #:510 0019 10
Reference #: 3182 001 002
Reference #: 471 3444 0
Reference #: 8186 4436
Reference #: FONN-7580 AA

 USE FOR HYDRAULIC CLUTCHES ONLY
 2 PORT
 ONLY USE HYDRAULIC FLUID

 Models: MXU115

Pilot Bearing
Part #:836108
 I.D - 1.440"
 O.D - 2.677"
 Thickness - .590

 Models: MXU115


Case-IH
14 INCH - FLEX PLATE
Disc
Part #:92590N
 Type - Spring Flex Plate
 Disc O.D - 14"
 Disc Hub Size - 1-3/4"
 Disc Spline - 13

 6 MOUNTING HOLES

 Models: 1440, 1460,
1480, 1620, 1640, 1660, 1680, 7110, 7120, 7130, 7140, 7150,
7210, 7220, 7230, 7240, 7250, 8910, 8920, 8930, 8940, 8950


Century
9 INCH - DUAL STAGE
Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: 2028

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: 2028


Century
9-1/4 INCH - DUAL STAGE
Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: C29

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: C29

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: C35

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: C35

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: C38L

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: C38L

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: C42L

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: C42L

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: C47L

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: C47L

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 2028

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2028

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 2035

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2035

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 2535

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 2535

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 3035

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3035

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 3040

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3040

Pilot Bearing
Part #:6011-2RS
Reference #: 832165
 I.D - 1.968"
 O.D - 3.147"
 Thickness - .620"

 USE AS RELEASE BEARING

 Models: 3045

Pilot Bearing
Part #:6302-2RS
 I.D - .590"
 O.D - 1.653"
 Thickness - .510"

 Models: 3045


Challenger
8-1/2 INCH - DUAL STAGE
Clutch Kit
Part #:FD320340N KIT-KUBOTA
 Includes: 6002-2RS, FD320340, K32420, N039

 Models: MT255

Clutch Kit
Part #:FD320340NR KIT-KUBOT
 Includes: 6002-2RS, FD320340, K32420-R, N039

 Models: MT255

Pressure Plate
Part #:FD320340
Reference #: K35260-14200
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-3/8" x 19
 Flywheel Step - .079
 Stage -Dual

 Models: MT255

Disc
Part #:K32420
Reference #: R18375
 Type - Spring Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: MT255

Disc
Part #:K32420-R
Reference #: CD2425
Reference #: R18374
 Type - Rigid Woven
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: MT255

Disc
Part #:K32420 HD4
Reference #: CD2425 HD4
Reference #: R18374 HD4
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: MT255

Disc
Part #:K32420-HD-6
Reference #: K32420-1440-CB
Reference #: R18375 HD6
 Type - Rigid Ceramic Button
 Disc O.D - 8-1/2"
 Disc Hub Size - 15/16"
 Disc Spline - 13

 Models: MT255

Release Bearing
Part #:N039
Reference #: 835511
 ID - 2.164"
 OD - 3.450"
 Thickness - 0.765"

 Models: MT255

Pilot Bearing
Part #:6002-2RS
Reference #: 15005
Reference #: 836002
 I.D - 0.590"
 O.D - 1.250"
 Thickness - 0.350"

 Models: MT255

Clutch Kit
Part #:FD320340N KIT-KUBOTA
 Includes: 6002-2RS, FD320340, K32420, N039

 Models: MT255B

Clutch Kit
Part #:FD320340NR KIT-KUBOT
 Includes: 6002-2RS, FD320340, K32420-R, N039

 Models: MT255B

Pressure Plate
Part #:FD320340
Reference #: K35260-14200
 Type - Lever
 Casting O.D. - 8-1/2"
 Levers - 3
 Springs - Belleville
 Hub/Spline - 1-3/8" x 19
 Flywheel Step - .079
 Stage -Dual

 Models: MT255B

Disc
Part #:K32420
